Description
225 HP
Perfect for 20-foot decks or deep-Vs, the versatile V6 4.2-liter F225 allows you to increase your displacement without replacing your rigging.
- Recommended fuel: 87 Octane
- Shaft length: 25”
- Alternator output: 50 amp
225 HP
| Weight † | 250 kg (551 lbs) — 254 kg (562 lbs) |
|---|---|
| Full Throttle RPM Range | 5000 ∼ 6000 RPM |
| Fuel Induction System | EFI |
| Recommended Engine Oil | Yamalube® 4M (See owner's manual) |
| Engine Type | V6 |
| Displacement | 4.2L |
| Bore x Stroke | 96 x 96mm (3.78 x 3.78 in) |
| Prop Shaft Horsepower | 225hp at 5500 RPM |
| Alternator Output at W.O.T. | 50 — 70 Amp |
| Compression Ratio | 10.3:1 |
| Recommended Fuel | Octane 87 |
| Recommended Fuel Filtration | Yamaha 10-Micron Fuel/Water Separating Filter (external) |
| C.A.R.B. Rating | 3-Star |
| Exhaust | Through Propeller |
| Intake | 24 |
| Ignition | TCI Microcomputer |
| Spark Plug | LFR6A-11 |
| Starting System | Electric |
| Lubrication | Wet Sump |
| Engine Oil Capacity | 6.3L / 6.0L |
| Recommended Cooling | Thermostatic Control |
| Ethanol Blend Limit | 10% Maximum |
| Gear Ratio | 1.75:1 |
| Gear Shift | Forward, Neutral, Reverse |
| Shaft Length | 25” — 30” |
| Degree of Tilt | 67° |
| Degree of Trim | −3° through +16° |
| Mounting Centers | 28.5” |
| Steering Angle (maximum) | 32° from center, either direction |
| Warranty | Limited 3-Year Pleasure, 3-Year Government, 1-Year Commercial |
225 HP
The V6 Offshore® 225 is compatible with mechanical controls and a range of gauges and props to suit your preference for performance, control, and the display of data. Explore compatible components below and contact your dealer for rigging expertise.
Compatible Controls
Helm Master® EX
N/A
Digital Controls
N/A
Mechanical Controls
Multi-Function Tiller Handle
N/A
Compatible Gauges
CL5 Touchscreen
N/A
Digital and Analog Gauges
Enter your details. Find the right prop. Easily zero-in on the best propeller options based on your type of craft, horsepower and performance goals with this smart, online tool.
